The sterilizing machine utilizes a plate heating exchanger. Our BP and BR series exchangers provide clients with the best-in-class performance. The compact structure is designed with a large heat exchanging surface area for high efficiency. The machine body occupies little space and can be easily disassembled, washed, and maintained. Our equipment utilizes a non-corrosive liquid medium that is especially designed for the treatment of stainless steel machinery; this medium is capable of relaying functions such as heating, cooling, heat recovery, and bacterial extermination.
This surface area or our automatically controlled heat exchanger is available in many different specifications, ranging between 0.3 and 700 square meters. The sterilizing machine widely utilized in industries such as beer, paper, power, chemical, beverage, fertilizer, petroleum, metallurgy, pharmaceutical, air conditioning, and biological engineering.
1) material 30℃→4℃ cool water 1℃ flow capacity 3:1
2) material 20℃→4℃ cool water 2℃ flow capacity 3:1
|Flow Capacity||Heat Exchanging Surface Area||Material Diameter||Media Diameter||Dimensions|
|1,000||1||Φ25||Φ25||350 ×210 ×600|
|2,000||2||Φ25/38||Φ38||600 ×285 ×810|
|3,000||3||Φ38||Φ38||600 ×285 ×810|
|4,000||4||Φ51||Φ51||600 ×470 ×1420|
|5,000||5||Φ51||Φ51||600 ×470 ×1420|
|6,000||6||Φ51/63||Φ51/63||600 ×470 ×1420|
|8,000||8||Φ51/63||Φ63||600 ×470 ×1420|
|10,000||10||Φ51/63||Φ63||800 ×590 ×1600|
|12,000||12||Φ63||Φ76||800 ×590 ×1600|
|15,000||15||Φ63/76||Φ76/101||800 ×680 ×1600|
|20,000||20||Φ63/76||Φ101||800 ×680 ×1600|
|30,000||30||Φ76||Φ101||800 ×680 ×1600|
As an experienced sterilizing machine manufacturer and supplier in China, our company provides a wide range of products, including storage tank, autoclave, milk receiving tank, falling film vacuum evaporator, and more.
