Coil Type Ultra-Temperature Flash Sterilizer
The coil type ultra-temperature flash sterilizer is ideal for the processing of wine, fruit juice, soy sauce, soy milk, fresh milk, condensed milk, and slurry from popsicle or ice cream. The device can also be utilized to eradicate bacteria from liquid medicine. The hand-controlled model is a type of manually operated sterilizer, its structure is shown in illustration one. The coil type ultra-temperature flash sterilizer consists of a main engine, material feeding pump, and various other components. The engine is equipped with a pressure gauge, sterilizing gauge, discharge temperature gauge, and two closing valves. Temperature changes during the sterilizing process are indicated via associated gauges.
| Model | UHT-1 | UHT-2 | UHT-4 |
| Processing Capacity(T/H) | 700-1000 | 1500-2000 | 3500-4000 |
| Sterilizing Temp. (℃) | 115-135 | ||
| Duration(s) | 4-6 | ||
| Discharge Temp. (℃) | ＜65 | ||
| Motor Power(kw) | 2.2 | 3 | 4(6) |
| Steam Pressure(MPa) | 0.78 | ||
| Steam Consumption (kg/h) | 0.25 | ||
| Dimensions(mm) | 1314 ×925 ×1650 | 1500 ×1050 ×1800 | 1750 ×1350 ×2000 |
As a specialized coil type ultra-temperature flash sterilizer manufacturer and supplier in China, Jiadi also provides stainless steel elevator, pre-heater, vertical type pouch packing machine, and spray dryer, among others.
